Android UI Tutorial - Android SlidingDrawer








The following code shows how to Use SlidingDrawer.

Example

Main layout xml file

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent">

    <SlidingDrawer
        android:id="@+id/drawer"
        android:layout_width="320dip"
        android:layout_height="440dip"
        android:orientation="vertical"
        android:handle="@+id/handle"
        android:content="@+id/content">

        <ImageView
            android:id="@+id/handle"
            android:layout_width="48dip"
            android:layout_height="48dip"
            android:src="@drawable/ic_launcher"  />

        <AnalogClock android:id="@+id/content"
            android:background="#D0A0A0"
            android:layout_width="fill_parent"
            android:layout_height="fill_parent" />

    </SlidingDrawer>

</RelativeLayout>

Main Activity Java code

import android.app.Activity;
import android.os.Bundle;
//from w  w  w  .j  a va2 s .c o m
public class MainActivity extends Activity {
    /** Called when the activity is first created. */
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);
    }
}
