TableLayout with two TableRow

Description

The following code shows how to create a TableLayout with two table rows.

Example

Layout xml


/*w w  w  .java  2s . c  o  m*/
<?xml version="1.0" encoding="utf-8"?>
<TableLayout
  xmlns:android="http://schemas.android.com/apk/res/android"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent"
  android:stretchColumns="1">
  <TableRow>
    <TextView
        android:text="URL:" />
    <EditText android:id="@+id/entry"
      android:layout_span="3"/>
  </TableRow>
  <View
    android:layout_height="2px"
    android:background="#0000FF" />
  <TableRow>
    <Button android:id="@+id/cancel"
      android:layout_column="2"
      android:text="Cancel" />
    <Button android:id="@+id/ok"
      android:text="OK" />
  </TableRow>
</TableLayout>

Java code


import android.app.Activity;
import android.os.Bundle;
//from ww w  .  j av a  2 s  .  com
public class TableLayoutDemo extends Activity {
  @Override
  public void onCreate(Bundle icicle) {
    super.onCreate(icicle);
    setContentView(R.layout.main);
  }
}
