Draw Oval with drawOval in Java

Description

The following code shows how to draw Oval with drawOval.

Example


/*from ww w  .  java2 s . c  o  m*/
import java.awt.Graphics;

import javax.swing.JComponent;
import javax.swing.JFrame;

class MyCanvas extends JComponent {
  public void paint(Graphics g) {
    g.drawOval (10, 10, 200, 200);

  }
}

public class Main {
  public static void main(String[] a) {
    JFrame window = new JFrame();
    window.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
    window.setBounds(30, 30, 450, 450);
    window.getContentPane().add(new MyCanvas());
    window.setVisible(true);
  }
}

The code above generates the following result.

Draw Oval with drawOval in Java
