Create a TableLayout with only one row

Description

The following code shows how to Create a TableLayout with only one row.

Example

Main layout xml file


<?xml version="1.0" encoding="utf-8"?>
<TableLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent">
    <TableRow>
        <TextView android:id="@+id/text_view_1"
            android:layout_width="150px"
            android:layout_height="100px"
            android:background="@android:color/darker_gray"
            />
        <TextView android:id="@+id/text_view_2"
            android:layout_width="150px"
            android:layout_height="100px"
            android:background="@android:color/white"
            />
    </TableRow>
</TableLayout>

Main Activity Java code


import android.app.Activity;
import android.os.Bundle;
//from   w  w w  .  j  av a2s .  co  m
public class MainActivity extends Activity {
    /** Called when the activity is first created. */
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        setContentView(R.layout.main);
    }
}
