Capture an Image and save to external storage

Description

The following code shows how to Capture an Image and save to external storage.

Example

Register permission


<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.java2s.myapplication3.app" >
    <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE"></uses-permission>

    <application
        android:allowBackup="true"
        android:icon="@drawable/ic_launcher"
        android:label="java2s.com"
        android:theme="@style/AppTheme" >
        <activity
            android:name="com.java2s.myapplication3.app.MainActivity"
            android:label="java2s.com" >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

Main layout xml file


<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:orientation="vertical"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent">
  <Button
    android:id="@+id/capture"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:text="Take a Picture"
  />
  <ImageView
    android:id="@+id/image"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:scaleType="centerInside"
  />
</LinearLayout>

Main activity Java code


import java.io.File;
import java.io.FileInputStream;
/*from  w w w. j  a v  a2 s  . com*/
import android.app.Activity;
import android.content.Intent;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.net.Uri;
import android.os.Bundle;
import android.os.Environment;
import android.provider.MediaStore;
import android.view.View;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.Toast;

public class MyActivity extends Activity {

    private static final int REQUEST_IMAGE = 100;

    Button captureButton;
    ImageView imageView;
    File destination;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);

        captureButton = (Button)findViewById(R.id.capture);
        captureButton.setOnClickListener(listener);

        imageView = (ImageView)findViewById(R.id.image);

        destination = new File(Environment.getExternalStorageDirectory(),"image.jpg");
    }

    @Override
    protected void onActivityResult(int requestCode, int resultCode, Intent data) {
        if(requestCode == REQUEST_IMAGE && resultCode == Activity.RESULT_OK) {
            //Bitmap userImage = (Bitmap)data.getExtras().get("data");
            try {
                FileInputStream in = new FileInputStream(destination);
                BitmapFactory.Options options = new BitmapFactory.Options();
                options.inSampleSize = 10; //Downsample 10x
                Bitmap userImage = BitmapFactory.decodeStream(in, null, options);
                imageView.setImageBitmap(userImage);
            } catch (Exception e) {
                e.printStackTrace();
            }

        }
    }

    private View.OnClickListener listener = new View.OnClickListener() {
        @Override
        public void onClick(View v) {
            Intent intent = new Intent(MediaStore.ACTION_IMAGE_CAPTURE);
            //Add extra to save full-image somewhere
            intent.putExtra(MediaStore.EXTRA_OUTPUT, Uri.fromFile(destination));
            Toast.makeText(MyActivity.this, Uri.fromFile(destination).toString(), Toast.LENGTH_SHORT).show();
            startActivityForResult(intent, REQUEST_IMAGE);
        }
    };
}
