Load data from Database to ListView

Description

The following code shows how to Load data from Database to ListView.

Example

Main layout activity_main.xml file


<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:orientation="vertical"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent">
  <EditText
    android:id="@+id/name"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
  />
  <Button
    android:id="@+id/add"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:text="Add New Person"
  />
  <ListView
    android:id="@+id/list"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
  />
</LinearLayout>

Main activity Java code


package com.java2s.myapplication3.app;
//from  w w w  .j a  v  a 2  s  .c om
import java.text.SimpleDateFormat;
import java.util.Date;

import android.app.Activity;
import android.content.ContentValues;
import android.database.Cursor;
import android.database.sqlite.SQLiteDatabase;
import android.os.Bundle;
import android.view.View;
import android.widget.AdapterView;
import android.widget.Button;
import android.widget.EditText;
import android.widget.ListView;
import android.widget.SimpleCursorAdapter;
import java.text.SimpleDateFormat;
import java.util.Date;

import android.content.ContentValues;
import android.content.Context;
import android.database.sqlite.SQLiteDatabase;
import android.database.sqlite.SQLiteOpenHelper;

public class MainActivity extends Activity implements View.OnClickListener, AdapterView.OnItemClickListener {

    EditText mText;
    Button mAdd;
    ListView mList;

    MyDbHelper mHelper;
    SQLiteDatabase mDb;
    Cursor mCursor;
    SimpleCursorAdapter mAdapter;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        mText = (EditText)findViewById(R.id.name);
        mAdd = (Button)findViewById(R.id.add);
        mAdd.setOnClickListener(this);
        mList = (ListView)findViewById(R.id.list);
        mList.setOnItemClickListener(this);

        mHelper = new MyDbHelper(this);
    }

    @Override
    public void onResume() {
        super.onResume();
        mDb = mHelper.getWritableDatabase();
        String[] columns = new String[] {"_id", MyDbHelper.COL_NAME, MyDbHelper.COL_DATE};
        mCursor = mDb.query(MyDbHelper.TABLE_NAME, columns, null, null, null, null, null, null);

        String[] headers = new String[] {MyDbHelper.COL_NAME, MyDbHelper.COL_DATE};
        mAdapter = new SimpleCursorAdapter(this, android.R.layout.two_line_list_item,
                mCursor, headers, new int[]{android.R.id.text1, android.R.id.text2});
        mList.setAdapter(mAdapter);
    }

    @Override
    public void onPause() {
        super.onPause();
        mDb.close();
        mCursor.close();
    }

    @Override
    public void onClick(View v) {
        ContentValues cv = new ContentValues(2);
        cv.put(MyDbHelper.COL_NAME, mText.getText().toString());
        SimpleDateFormat dateFormat = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
        cv.put(MyDbHelper.COL_DATE, dateFormat.format(new Date())); //Insert 'now' as the date
        mDb.insert(MyDbHelper.TABLE_NAME, null, cv);

        mCursor.requery();
        mAdapter.notifyDataSetChanged();

        mText.setText(null);
    }

    @Override
    public void onItemClick(AdapterView<?> parent, View v, int position, long id) {

        mCursor.moveToPosition(position);

        String rowId = mCursor.getString(0); //Column 0 of the cursor is the id
        mDb.delete(MyDbHelper.TABLE_NAME, "_id = ?", new String[]{rowId});

        mCursor.requery();
        mAdapter.notifyDataSetChanged();
    }
}

class MyDbHelper extends SQLiteOpenHelper {

    private static final String DB_NAME = "mydb";
    private static final int DB_VERSION = 1;

    public static final String TABLE_NAME = "people";
    public static final String COL_NAME = "pName";
    public static final String COL_DATE = "pDate";
    private static final String STRING_CREATE =
            "CREATE TABLE "+TABLE_NAME+" (_id INTEGER PRIMARY KEY AUTOINCREMENT, "
                    +COL_NAME+" TEXT, "+COL_DATE+" DATE);";

    public MyDbHelper(Context context) {
        super(context, DB_NAME, null, DB_VERSION);
    }

    @Override
    public void onCreate(SQLiteDatabase db) {
        db.execSQL(STRING_CREATE);

        ContentValues cv = new ContentValues(2);
        cv.put(COL_NAME, "Jack");

        SimpleDateFormat dateFormat = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
        cv.put(COL_DATE, dateFormat.format(new Date())); //Insert 'now' as the date
        db.insert(TABLE_NAME, null, cv);
    }

    @Override
    public void onUpgrade(SQLiteDatabase db, int oldVersion, int newVersion) {
        db.execSQL("DROP TABLE IF EXISTS "+TABLE_NAME);
        onCreate(db);
    }
}
