Android UI How to - Use LinearLayout to layout widgets








The following code shows how to use LinearLayout to layout widgets.

Example

Add the following code in bold to the res/layout/ your main xml file for layout:

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical" >
//from w  ww . j  a  va2s.  c om
    <TextView
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="hello" />

    <TextView
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="This is my first Android Application!" />

    <Button
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="And this is a clickable button!" />

</LinearLayout>

Java code

package com.java2s.app;
/*from   ww  w.  j a v  a  2  s  . c om*/
import android.app.Activity;
import android.os.Bundle;

public class MainActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

    }

}
null
