Android UI How to - Create custom view from FrameLayout








The following code shows how to Create custom view from FrameLayout.

Example

Main Activity Java code

import android.app.Activity;
import android.content.Context;
import android.graphics.drawable.Drawable;
import android.util.AttributeSet;
import android.view.Gravity;
import android.view.View;
import android.widget.FrameLayout;
import android.widget.ImageView;
import android.widget.TextView;
/*from   w w w .j a va  2  s .c  o  m*/
import android.os.Bundle;
import android.content.Context;
import android.content.res.TypedArray;
import android.graphics.Canvas;
import android.graphics.Color;
import android.graphics.Paint;
import android.graphics.Paint.Style;
import android.graphics.Point;
import android.util.AttributeSet;
import android.view.View;
public class MyActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        TextImageButton myView = new TextImageButton(this);
        myView.setText("Text");
        myView.setImageResource();
        setContentView(myView);
    }
}
class TextImageButton extends FrameLayout {

    private ImageView imageView;
    private TextView textView;

    public TextImageButton(Context context) {
        this(context, null);
    }

    public TextImageButton(Context context, AttributeSet attrs) {
        this(context, attrs, 0);
    }

    public TextImageButton(Context context, AttributeSet attrs, int defaultStyle) {
        super(context, attrs, android.R.attr.buttonStyle);
        imageView = new ImageView(context, attrs, defaultStyle);
        textView = new TextView(context, attrs, defaultStyle);

        FrameLayout.LayoutParams params = new FrameLayout.LayoutParams(
                    LayoutParams.WRAP_CONTENT,
                    LayoutParams.WRAP_CONTENT,
                    Gravity.CENTER);

        this.addView(imageView, params);
        this.addView(textView, params);

        if(imageView.getDrawable() != null) {
            textView.setVisibility(View.GONE);
            imageView.setVisibility(View.VISIBLE);
        } else {
            textView.setVisibility(View.VISIBLE);
            imageView.setVisibility(View.GONE);
        }
    }
    public void setText(CharSequence text) {
        textView.setVisibility(View.VISIBLE);
        imageView.setVisibility(View.GONE);
        textView.setText(text);
    }

    public void setImageResource(int resId) {
        textView.setVisibility(View.GONE);
        imageView.setVisibility(View.VISIBLE);
        imageView.setImageResource(resId);
    }
    public void setImageDrawable(Drawable drawable) {
        textView.setVisibility(View.GONE);
        imageView.setVisibility(View.VISIBLE);
        imageView.setImageDrawable(drawable);
    }
}
