Android UI How to - CheckBox state change event








To implement specific logic when a check box is checked or unchecked, you can register for the on-checked event by calling setOnCheckedChangeListener() with an implementation of the OnCheckedChangeListener interface.

Then implement the onCheckedChanged() method, which will be called when the check box is checked or unchecked.

Example

Java code

package com.java2s.app;
/*w  w  w  .  j a  va2  s  . c o m*/
import android.app.Activity;
import android.os.Bundle;
import android.util.Log;
import android.widget.CheckBox;
import android.widget.CompoundButton;

public class MainActivity extends Activity {
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        CheckBox fishCB = (CheckBox) findViewById(R.id.fishCB);

        if (fishCB.isChecked()) {
            fishCB.toggle();     // flips the checkbox to unchecked if it was checked
        }
        fishCB.setOnCheckedChangeListener(
                new CompoundButton.OnCheckedChangeListener() {
                    @Override
                    public void onCheckedChanged(CompoundButton arg0, boolean isChecked) {
                        Log.v("CheckBoxActivity", "The fish checkbox is now "
                                + (isChecked ? "checked" : "not checked"));
                    }
                }
        );
    }
}

XML layout file.

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical">
/*  w  ww . ja  v  a2s  .c o  m*/
    <CheckBox
        android:id="@+id/chickenCB"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:checked="true"
        android:text="XML" />

    <CheckBox
        android:id="@+id/fishCB"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="CSS" />

    <CheckBox
        android:id="@+id/steakCB"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:checked="true"
        android:text="HTML" />

</LinearLayout>
