Android How to - Set system UI to full screen








The following code shows how to Set system UI to full screen.

Example

Main layout xml file

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent" >
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_centerVertical="true"
        android:text="Toggle Mode"
        android:onClick="onToggleClick" />
</RelativeLayout>

Main Activity Java code

import android.app.Activity;
import android.os.Bundle;
import android.view.View;
import android.view.Window;
/*from   ww w  . j av  a 2  s .c o m*/
public class MainActivity extends Activity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        requestWindowFeature(Window.FEATURE_ACTION_BAR_OVERLAY);
        setContentView(R.layout.main);

    }

    public void onToggleClick(View v) {
        v.setSystemUiVisibility(
                View.SYSTEM_UI_FLAG_LAYOUT_STABLE
                | View.SYSTEM_UI_FLAG_FULLSCREEN
                | View.SYSTEM_UI_FLAG_HIDE_NAVIGATION);
    }
}
null
